PlantUML Diagram Skill

Generates and renders PlantUML diagrams to real PNG/SVG via the Kroki API, with a validate-and-self-correct loop.

by Agents365-ai · Agents365-ai/plantuml-skill

Tested · Works

Install — copy the command Download source ↗

Test report

Verdict: Tested · Works
Score: 9.6/10
Tested: Jul 14, 2026
Environment: Claude Code 2.x (agent harness)
Upstream re-checked: Aug 10, 2026 · 01e7835

Ran the real render loop against the live public Kroki API: POST returned HTTP 200, a genuine 715x376 PNG landed on disk, and the vision self-check confirmed it was clean and readable — the baseline path only produces unverified .puml text with no proof it even renders.

Scored on four weighted criteria — install, triggering, output vs. baseline, docs. How scoring works

Installs cleanly 5/5
Triggers reliably 5/5
Output vs. baseline 9/10
Docs & honesty 5/5

What PlantUML Diagram Skill does

Writes .puml source for sequence/class/ER/component/activity/state/C4 diagrams and exports it to PNG/SVG through the free Kroki API (curl only, no local Java/Graphviz needed). Triggers on explicit diagram requests and proactively when explaining systems with 3+ components; explicitly routes non-UML markdown diagrams to mermaid and hand-drawn styles to excalidraw/tldraw rather than over-claiming.

How to install PlantUML Diagram Skill

git clone https://github.com/Agents365-ai/plantuml-skill
cd plantuml-skill
mkdir -p ~/.claude/skills
cp -r skills/plantuml-skill ~/.claude/skills/plantuml-skill

Skills live in ~/.claude/skills/ (global) or .claude/skills/ (per-project). Restart Claude Code after installing.

Commands — how to trigger PlantUML Diagram Skill

/plantuml-skill Generates and renders PlantUML diagrams to real PNG/SVG via the Kroki API, with a validate-and-self-correct loop.

It also activates on plain-language prompts like these:

Render a sequence diagram for our login flow as a PNG
Draw a UML diagram of the client-to-auth-service handshake
Generate a PlantUML diagram and fix it until it renders
