Logic MSO Analysis

Decodes UART/SPI/I2C/1-Wire from Saleae Logic MSO binary exports for CTF and hardware RE.

by BrownFineSecurity · BrownFineSecurity/iothackbot

Works with setup

Install — copy the command Download source ↗

Test report

Verdict: Works with setup
Score: 7.6/10
Tested: Jul 13, 2026
Environment: Claude Code 2.x (agent harness)
Upstream re-checked: Aug 10, 2026 · 49b33ba

Built a synthetic 2-byte ('Hi') UART capture and ran the SKILL.md's own decode_uart_byte() verbatim: its center-of-bit-period sampling correctly recovered the first byte where a naive from-scratch baseline sampler got it wrong ('X' instead of 'H') — but the surrounding multi-byte loop example in the same doc has a real bug that causes it to silently stop after one byte on any multi-byte capture.

Scored on four weighted criteria — install, triggering, output vs. baseline, docs. How scoring works

Installs cleanly 4/5
Triggers reliably 5/5
Output vs. baseline 6/10
Docs & honesty 4/5

What Logic MSO Analysis does

Loads Saleae Logic MSO binary captures via the saleae-mso-api Python library and gives timing-cluster heuristics plus worked Python examples for decoding UART, SPI, I2C, and 1-Wire signals, aimed at CTF challenges and hardware reverse engineering. Ships a bundled analyze_protocol.py CLI (histogram/cluster/CSV export modes) and an examples.md walkthrough for unknown-protocol triage.

How to install Logic MSO Analysis

git clone https://github.com/BrownFineSecurity/iothackbot
cd iothackbot
mkdir -p ~/.claude/skills
cp -r skills/logicmso ~/.claude/skills/logicmso

Skills live in ~/.claude/skills/ (global) or .claude/skills/ (per-project). Restart Claude Code after installing.

Commands — how to trigger Logic MSO Analysis

/logicmso Decodes UART/SPI/I2C/1-Wire from Saleae Logic MSO binary exports for CTF and hardware RE.

It also activates on plain-language prompts like these:

Decode this UART capture from my Saleae Logic MSO export file
I have an unknown protocol dump, help me cluster timing and identify SPI or I2C
Analyze this Logic MSO binary capture for a CTF hardware reverse engineering challenge
