GPIO Config

GPIO pin assignment, conflict validation, and init code for Pi and ESP32.

by claudius-ars · claudius-ars/embedded-agent-skills

Works with setup

Install — copy the command Download source ↗

Test report

Verdict: Works with setup
Score: 7.6/10
Tested: Jul 15, 2026
Environment: Claude Code 2.x (agent harness)
Upstream re-checked: Aug 10, 2026 · 084a891

Real, working pin-safety logic — validate_pinmap.py correctly caught a GPIO2 strapping-pin hazard on an ESP32 status LED that a naive baseline answer would have missed. But the script crashes on the exact JSON the docs teach: SKILL.md's own schema and worked Section-8 example pass protocol_bus as an integer (0, 1), while the code calls protocol_bus.lower() expecting a string like "i2c" — AttributeError: 'int' object has no attribute 'lower'. Fix is to pass protocol_bus as a lowercase protocol name string, undocumented.

Scored on four weighted criteria — install, triggering, output vs. baseline, docs. How scoring works

Installs cleanly 5/5
Triggers reliably 5/5
Output vs. baseline 7/10
Docs & honesty 2/5

What GPIO Config does

Assigns and validates GPIO pin maps for Raspberry Pi and ESP32 boards, flagging strapping pins, flash-reserved pins, and current-budget issues before they brick hardware. Triggers on GPIO/wiring/pin-conflict questions or when a named sensor/board pair (e.g. 'BME280 on a Pi 4') implies pin selection, and generates gpiozero/RPi.GPIO/Arduino/ESP-IDF init code.

How to install GPIO Config

git clone https://github.com/claudius-ars/embedded-agent-skills
cd embedded-agent-skills
mkdir -p ~/.claude/skills
cp -r embedded-agent-skills/gpio-config ~/.claude/skills/gpio-config

Skills live in ~/.claude/skills/ (global) or .claude/skills/ (per-project). Restart Claude Code after installing.

Commands — how to trigger GPIO Config

/gpio-config GPIO pin assignment, conflict validation, and init code for Pi and ESP32.

It also activates on plain-language prompts like these:

Wire a BME280 and an SSD1306 OLED to my ESP32 over I2C, give me the pins
Check this Raspberry Pi pinout for strapping-pin or current-budget conflicts
Generate gpiozero init code for a sensor I'm wiring to a Pi 4
