Draw.io Diagrams

Generates valid, styled draw.io XML diagrams with colors, icons, and legends.

by scarr05 · scarr05/claude-skills-pub

Tested · Works

Install — copy the command Download source ↗

Test report

Verdict: Tested · Works
Score: 9.6/10
Tested: Jul 16, 2026
Environment: Claude Code 2.x (agent harness)
Upstream re-checked: Aug 10, 2026 · 3c5be28

Generated a real 3-tier architecture diagram: the skill's mxCell conventions (html=1, fillColor tiers, cylinder DB shape, legend) produce XML that actually renders correctly in draw.io, while a naive from-memory attempt used bare style strings (no html=1, no fill, no arrowheads) that draw.io renders as broken unstyled boxes.

Scored on four weighted criteria — install, triggering, output vs. baseline, docs. How scoring works

Installs cleanly 5/5
Triggers reliably 5/5
Output vs. baseline 9/10
Docs & honesty 5/5

What Draw.io Diagrams does

Produces .drawio (mxfile/mxGraphModel) XML for architecture diagrams, flowcharts, network topology and wireframes, importable directly into draw.io/diagrams.net. Triggers on requests to create diagrams, architecture visuals, flowcharts or wireframes, and bundles AWS/Azure/GCP icon references plus a customisable brand palette.

How to install Draw.io Diagrams

git clone https://github.com/scarr05/claude-skills-pub.git
mkdir -p ~/.claude/skills
cp -r claude-skills-pub/drawio-skill ~/.claude/skills/drawio

Skills live in ~/.claude/skills/ (global) or .claude/skills/ (per-project). Restart Claude Code after installing.

Commands — how to trigger Draw.io Diagrams

/drawio Generates valid, styled draw.io XML diagrams with colors, icons, and legends.

It also activates on plain-language prompts like these:

Draw a three-tier architecture diagram I can open in draw.io
Make me a network topology diagram with AWS icons and a legend
Generate a flowchart XML file for our onboarding process
