D2 Diagram Generator for Azure

Turns Terraform Azure infra into icon-accurate D2 architecture diagrams via a mandatory scope questionnaire and live icon lookup.

by miiitch · miiitch/d2-gen

Works with setup

Install — copy the command Download source ↗

Test report

Verdict: Works with setup
Score: 8.4/10
Tested: Jul 14, 2026
Environment: Claude Code 2.x (agent harness)
Upstream re-checked: Aug 10, 2026 · a1cc790

Ran it for real on a 3-resource Terraform snippet (Function App + Storage + Service Plan): it correctly resolved live Azure icons from the repo's own GitHub-hosted JSON index and rendered a valid SVG via `d2 --layout=elk --theme=1` - but its description advertises Bicep support while the SKILL.md's own Icon Source Requirement section only ever wires in the Terraform icon mapping URL, so a real Bicep diagram would silently fall back to plain rectangles for every single resource despite a working icon-index-bicep-png.json sitting unused in the same repo.

Scored on four weighted criteria — install, triggering, output vs. baseline, docs. How scoring works

Installs cleanly 5/5
Triggers reliably 5/5
Output vs. baseline 9/10
Docs & honesty 2/5

What D2 Diagram Generator for Azure does

Reads Terraform/Terragrunt (and, per its own description, Bicep) Azure infrastructure code and generates D2 diagram source with real Azure service icons, resource-group containers, hidden-sub-resource styling, and rule-based internet-exposure detection, then renders it via the external d2 CLI. Triggers on requests to diagram Terraform/Azure infrastructure; explicitly excludes runtime debugging and draw.io output. Requires the d2 CLI to be installed separately and is documented in its own repo README as a GitHub Copilot skill with no Claude-specific install instructions, though the SKILL.md format itself works fine when copied into a Claude skills folder.

How to install D2 Diagram Generator for Azure

git clone https://github.com/miiitch/d2-gen
cd d2-gen
mkdir -p ~/.claude/skills
cp -r skills/d2-gen-azure ~/.claude/skills/d2-gen-azure

Skills live in ~/.claude/skills/ (global) or .claude/skills/ (per-project). Restart Claude Code after installing.

Commands — how to trigger D2 Diagram Generator for Azure

/d2-gen-azure Turns Terraform Azure infra into icon-accurate D2 architecture diagrams via a mandatory scope questionnaire and live icon lookup.

It also activates on plain-language prompts like these:

Turn my Terraform Azure setup into an architecture diagram
Draw our cloud infra with proper Azure service icons
Which of my Azure resources are exposed to the internet?
